3 Axis Wood Lathe Machine for Custom Wood Turning
3 axis wood lathe machine with three turning axis, which can turn 3 pieces wood columns with maximum 120mm diameter and 1500mm length at the same time. The 3 axis wood turning lathe machine processing length can be customized to 2000mm, 2500mm or 3000mm.
Product Descriptions
3 Axis wood lathe machine for CustomWood Turning Applications
3 Axis wood turning lathe Machine is applied towooden cup, wooded bowl, tubular shape and vehicle wood crafts, cylindrical workpiece, staircase column, Roman column, general column, table or chair legs, washstand, wooden vase, wooden tables, baseball bats, car wooden furnitures, children’ s bed columns, etc. 3 Axis Wood Turning Lathe Machinecan be equipped with spindles with function of carving, slotting, hollowing on wood strip.
Technical Parameters of 3 Axis wood lathe Machine for CustomWood Turning
| Brand | APEXCNC |
| Model | APEX1512-3S3 |
| Max turning length | 1500mm |
| Max turning diameter | 120mm |
| Number of axis | 3 axis |
| Maximum feed rate | 2000mm/min |
| Minimum setting unit | 0.1mm |
| Spindle motor power | 3.5kw air cooling spindle |
| software | including |
| Power supply | AC380v/50hZ |
| Price Range | $8,280.00 – $8,680.00 |
3 Axis Wood Lathe Machine for CustomWood Turning Features
1. Big torque stepper motor and Yako driver guarantee wood turning with high speed.
2. Driving system: High quality square rails from Taiwan Hiwin and TBI precise ball screw, which can control the linear error effectively.
3. Best inveter: The wood turning lathe machine adopts frequency conversion speed regulation system, which can adjust the turning speed at any time to solve the problem of materials
