Factory Cheap Hot China 6090 CNC Router Desktop Mini CNC Engraving Machine 1.5kw Water Cooling Spindle

Short Description:

The  Hobby  wood cutting milling machine cnc router table for sale is one type of cnc router machine with mini table size. It is small and easy to operate.This Hobby  wood cutting milling machine cnc router table for sale  is widely used in advertisement,handicraft and mold.


Product Detail

Product Tags

Usually customer-oriented, and it’s our ultimate focus on being not only one of the most responsible, trustable and honest provider, but also the partner for our clients for Factory Cheap Hot China 6090 CNC Router Desktop Mini CNC Engraving Machine 1.5kw Water Cooling Spindle, High-quality is factory’s everyday living , Focus on customers’ demand would be the source of organization survival and advancement, We adhere to honesty and good faith doing the job attitude, seeking forward towards your coming !
Usually customer-oriented, and it’s our ultimate focus on being not only one of the most responsible, trustable and honest provider, but also the partner for our clients for China Wood CNC Router, mini cnc router, If you are for any reason unsure which product to select, do not hesitate to contact us and we’ll be delighted to advise and assist you. This way we will be providing you with all the knowledge needed to make the best choice. Our company strictly follows “Survive by good quality, Develop by keeping good credit. ” operation policy. Welcome all the clients old and new to visit our company and talk about the business. We’re looking for more and more customers to create the glorious future.
1) Water cooling spindle, with high precision, long life time, steady working, easy to start up.
2) Taiwan Hiwin linear square guide rail, self-lubricating sliding block. It ensures equal
force in all directions and accuracy and strength of the machine.
3) Taiwan TBI ball Screw transmit, ensured high accuracy and stable when working.
4) Stepper motors and Drivers, 3 sets in total, with big torque, ensure machine stable.
5) DSP controller system with USB interface,working without connecting with computer
during working and easy to control.

Descriptions of Machine

Description Parameter
X,Y,Z Working Area 600mmx900mmx80mm
Table Size 750mm×1050mm
Table Surface T-slot Table
Spindle Power 1.5KW water cooling spindle
Spindle Speed 0-24000RPM
Motors Stepper motors
Driver Leadshine or YAKO driver
Transmission X,Y,Z Axis: Taiwan TBI ball Screw
Machine Guide Rails Taiwan Hiwin Linear square guide rail
Inverter Fuling or Delta Inverter
Operating System DSP control system
Soft Limit switch Japan Omron limit
AC contactor France Schneider
X,Y,Z Traveling Positioning Accuracy ±0.03/300mm
X,Y,Z Repositioning Accuracy ±0.02mm
Max. Rapid Travel Rate 12000mm/min
Max. Working Speed 8000mm/min
Max. Power Consumption 3KW(Without Spindle)
Working Voltage AC220V/60Hz
Command Language G Code
Computer Interface USB
Flash Memory 128M(U Disk)
Collet ER20
Software Compatibility Artcam OR Type3 Software
Running Environment Temperature 0 - 45 Centigrade
Relative Humidity 30% - 75%
Packing Size 1710 x 1250 x 1585mm
N.W. 150KG
G.W. 200KG
Optional Parts Spindle: Air cooling spindle can be choose
Motor and Driver: Servo system
Japan: Yaskawa / Panasonic servo
China: Taiwan Delta servo
Control system:  NC Studio/Syntec/mach3
Dust Collector
Rotary System
Mist-cooling System

APEX 6090 cnc router (2)

How to Order Our Machine?
Before we can recommend you the best suitable machine, please kindly tell us:

1)  What materials will you work on?
2)  What is your Max.size of your processing materials? ( Length & Width )
3)  Do you mainly engrave or cut? If cut,What is your Max.cutting thickness?
4)  Does your materials are cylinder? If YES, what’s the Max. Diameter of it?
5)  If it is possible, could you send us your product samples’ picture? It will help us better to
understand.

Trade Items of Machine

MOQ 1 set
Package Standard Plywood Box
Delivery Terms FOB, CIF, EXW, Door to Door ect.
Delivery Time 15 working days after receiving payment
Payment Type T/T, Paypal, Western Union and others
Supply Ability 200 sets/month
Port Qingdao, China.







7.  Guarantee & Service of Machine
1) We would provide English Version working manual.
2) If you have any questions during using and maintaining, our engineers who could speak
very good English would answer you online or by calls.
3) Machine warranty is one year. So if your machine has any unintentional damages, we would
provide parts for free.
4) If your machine has big problems if by any chance, our engineers would arrive there to debug
and fix.
5) Could be remote control if needed.





 Usually customer-oriented, and it’s our ultimate focus on being not only one of the most responsible, trustable and honest provider, but also the partner for our clients for Factory Cheap Hot China 6090 CNC Router Desktop Mini CNC Engraving Machine 1.5kw Water Cooling Spindle, High-quality is factory’s everyday living , Focus on customers’ demand would be the source of organization survival and advancement, We adhere to honesty and good faith doing the job attitude, seeking forward towards your coming !
Factory Cheap Hot China Wood CNC Router, Mini CNC Router, If you are for any reason unsure which product to select, do not hesitate to contact us and we’ll be delighted to advise and assist you. This way we will be providing you with all the knowledge needed to make the best choice. Our company strictly follows “Survive by good quality, Develop by keeping good credit. ” operation policy. Welcome all the clients old and new to visit our company and talk about the business. We’re looking for more and more customers to create the glorious future.
