Factory Supply 2060 Square Pipe Fiber Laser Cutting Machine for Stainless Steel

Short Description:

APEX2060 has a powerful cutting function, pneumatic three chucks, can cut square pipes, round pipes, rectangular pipes and various special-shaped pipes; processing pipe diameter and length range can be customized (standard round pipe diameter Φ30~160mm, length 12000mm).
Adopt chucks and push-type cutting method, with high centering precision and processing precision.

Send email to us

Product Detail

Product Tags

Advantages
1.Professional pipe/tube cutting machine with pneumatic three chuck design that can automatically identify the size and the center point of the pipe when clamping the pipe, with high centering and processing accuracy to ensure high-quality.
2. 3 chucks professional pipe cutting machine of Glorystar Laser, it’s head and tail chuck can easily turn around to cutting to realize Zero-tailing cutting which saves material costs more than 20,000USD.
3. APEX2060 Fiber Laser tube cutting machine with 3 chucks can realize “0″-tailing cutting with higher tube utilization rate and lower cost. Cutting length can be up to 6 meters with non-deformation, bring long-standing working accuracy!
4. Professional tube cutting machine APEX2060 of Glorystar Laser with a fully automatic loading device which finishes automatically loading materials work, bring lower labor costs, and higher productivity.

Specifications

No.	Item	Parameter
	Maximum Travelling speed	70m/min
	Laser wavelength	1070-1080 nm
	Minimum cutting width	0.2mm
	Rated output power	10–100% (100W-1000W)
	X And Y axis positioning accuracy	≤±0.03mm
	Repeat positioning accuracy	≤±0.02mm
	Available cut pipe shape	Square, Round, Rectangular, Oval, Angle, Channel, etc.
	Acceleration	1G
	Oiling systems	Automatic oiling
	Effective length of cutting	6000mm/8000mm/10000mm(customized order acceptable)
	Size(LT-6020)	113.92.5m (Length * width * height)
	Power	35KW
	Power supply	380v50Hz ±10%
	Red Positioning	Yes
	Auxiliary gases	Oxygen, Nitrogen, Air
	Supported file formats	IGS (Available PRO/E. UG, Solid works Photo)
	Diameter	20mm-220mm (customized order acceptable)
	Laser tracking system	Automatic follow-up
	Tail Waste Length	<180mm

Application
1.Applicable to all kinds of commonly used closed and non-closed metal pipe processing, such as: square pass, round pipe, elliptical pipe, angle iron, channel steel, I-beam, etc.
2.Application industry: kitchen utensils, lighting hardware, precision parts, sheet metal processing and other metal products processing industries;
3.Application materials: carbon steel, stainless steel, copper, aluminum, galvanized pipe, electrolytic plate and other metal materials.

Warranty and Service
1.Guarantee for 5 years.
2. Maintenance free of charge for 5 years .
3.We will provide the consumable parts at an agency price.
4.24 hours online service, free technical support.
5.Machine has been adjusted before delivery, operation disk is included in the delivery. If there is any other questions, pls kindly tell me.
6.We have manual instruction and CD (Guiding Videos) for software Installation, operation and machine’s using and maintenance.
