Previously, most of the equipment used in the furniture industry during production was a sliding table saw. This type of equipment is not only time-consuming and labor-intensive, but also improves labor capacity. Now, the panel furniture production line cutting machine has greatly improved processing efficiency, saved processing time, and is very simple to operate. With the normal use of the equipment, there are more and more manufacturers, and the quality of each brand is uneven. Therefore, when choosing, the accuracy of the equipment is a very important inspection point. So do you know how to detect the accuracy of the CNC cutting machine of the panel furniture production line equipment? How much do you know about this? Next, Blue Elephant CNC will summarize it in detail for everyone, hoping to help everyone.

Method 1: Process the board, measure whether the diagonal lines of the board are the same, whether the opposite side dimensions are the same, and whether the hole edges are the same.

Method 2: Process the neutral board on both sides of the cabinet and check the positioning accuracy of the flip board. Under normal circumstances, the positioning accuracy requirements for single-sided processing are not too strict, and the positioning cylinder mainly affects the flip processing accuracy. Punch a hole on a board, open a double-sided groove, see if the hole is transparent, whether there are any docking marks, and measure the hole edges and groove edges on both sides.

Method 3: Processing accuracy of small boards, requiring small board processing. According to the several small wooden boards that will appear in the production, such as the 300mm*50mm drawer side panels, we can look at the adsorption capacity of the desktop to see if there will be board running. In addition, we can also measure the processing accuracy of small wooden boards.

Method 4: Two boards of the same specification can be cut on one board, and the four corners can be punched with wooden pins.
These are a few simple methods to detect accuracy. The purpose of purchasing cutting machine equipment is to save time and effort, improve the utilization rate of boards, improve processing efficiency, improve processing accuracy, and improve quality. A good cutting machine can make you get twice the result with half the effort. A poor CNC cutting machine not only wastes manpower, material and financial resources, but may even ruin your career.

The method of testing the CNC cutting machine of the panel furniture production line has been summarized in detail in the above content. When processing boards, be sure to measure the diagonal of the boards to ensure the accuracy of the processed products. In short, it is important to choose reliable manufacturers and equipment. Don’t be greedy for cheapness, otherwise it will not be worth the loss.
