Raycus Laser
The laser has higher photoelectric conversion efficiency, better and more stable beam quality, and stronger Anti-high anti-reaction ability. At the same time, it introduces an optimized second- generation optical fiber transmission system to ensure more stable and precise welding of thick plates. welding effect. This product is suitable for a variety of applications: cutting, welding, drilling, medical device processing, etc. The welded plate welds are smooth and bright, which has obvious advantages over other lasers of the same type in the market.
Features
High photoelectric conversion efficiency
Maintenance-free operation
Efficient thin plate cutting
Output fiber length can be customized
Modulation frequency range
Anti-high anti-reaction ability
QBH connector
Optical Properties
Average output power: (W): 1500 Output power stability: ±1.5%
Center wavelength: (nm): 1080±5
Red light indicates output power (mW）: 0.1-1
Modulation frequency: (kHz): 50~20,000
Output Characteristics
Output connector: QBH (can be customized)
Output fiber length (m): 20 (customizable)
Beam quality M2: 1.3 (25μm)
Polarization State: Random
Electronically Controlled
Input power (VAC): 200-240, single phase
Control mode：External RS232, External AD, HyperTerminal
Power adjustment range (%): 10-100
